The transceiver is equipped with function ports that can be programmed using KPG-D1/ D1N.
11.1
Universal Connector
Supported Models: Portable
For Portable, the transceiver is equipped with a function port that can be programmed for use with the 14-pin universal
connector
located on the side of the transceiver. The Vibrator unit and GPS receiver unit can be connected to the transceiver
via the universal connector.
Assigning Functions to the Universal Connector
Pin 11 of the universal connector can be used with the following functions according to the user’s purpose of use.
Table 11-1 Available Functions to be Assigned to Pin 11
Function Description
AUX
When the AUX function is enabled by pressing the AUX
key, or by pressing the Menu key to enter
Menu Mode and then selecting “AUX”, the 5 V power source is supplied to pin 11 of the universal
connector. The transceiver stops supplying 5 V when the AUX function is disabled. A maximum
of 200 mA current can be supplied to pin 11.
Vibrator
If activation conditions of the vibrator are satisfied while the Vibrator function is enabled, the 5 V
power source is supplied to pin 11 at 500-ms intervals for 10 sec. The vibrator unit (KCT-48VU)
connected to the universal connector notifies a user by vibrating.
Always 5 V (high)
This configuration is applied when using external devices that always require a power source,
such as a speaker microphone and a headset.
The transceiver behavior varies as below depending on the configuration in Output Control by
SSW.
If the Output Control by SSW is configured to be enabled:
The
5 V power source is supplied to pin 11 if pin 1 (SSW) of the universal connector is low level.
If the Output Control by SSW is configured to be disabled:
The 5 V power source is always supplied to pin 11 regardless of the status of pin 1 (SSW) of
the universal connector.
HRS Adapter
The 5 V power source is always supplied to pin 11 of the universal connector. This configuration
is
applied when the KCT-51 is used. HRS Adapter can be used to easily connect audio accessories
or similar to the KCT-51. This configuration is also applied when an external device that always
requires a power source is used.
Note
0
Refer to “Using Menu Mode” for operations in Menu Mode.
0
If the Vibrator key is not configured while “Vibrator” is configured in Universal Connector Pin Number 11, the Vibrator
function is automatically enabled when the transceiver is turned ON.
Configuration using KPG-D1/ D1N
0
Configuring Universal Connector Pin Number 11 ( Transceiver Settings > Extended Function > Universal
Connector)
0
Configuring Output Control by SSW to be enabled or disabled ( Transceiver Settings > Extended Function >
Always 5V (high))
