Migrating to a Zone-channel by Using a Connected External Device (Remote Zone-
Channel)
Remote Zone-Channel is the function to migrate to one of a maximum of 15 zones and channels by using the Channel
Select A to Channel Select D ports.
The transceiver migrates to a zone and channel configured in the Remote Zone-Channel List if one of the Channel Select
A to Channel Select D ports goes low level.
Table 11-10 Remote Zone-Channel List Number Corresponding to Each Channel Select Port
Remote Zone-
Channel
AUX Input port
Channel Select D Channel Select C Channel Select B Channel Select A
No.1 High High High Low
No.2 High High Low High
No.3 High High Low Low
No.4 High Low High High
No.5 High Low High Low
No.6 High Low Low High
No.7 High Low Low Low
No.8 Low High High High
No.9 Low High High Low
No.10 Low High Low High
No.11 Low High Low Low
No.12 Low Low High High
No.13 Low Low High Low
No.14 Low Low Low High
No.15 Low Low Low Low
Not Configured
*1
High High High High
*1
If Remote Zone-Channel is not configured, the transceiver cannot migrate to a zone or channel.
Note
A zone and channel for which no channel data is configured cannot be configured in the Remote Zone-Channel List.
Configuration using KPG-D1/ D1N
0
Assigning functions to the AUX Input port (
Transceiver Settings > Extended Function > AUX)
0
Configuring Remote Zone-Channel List (
Transceiver Settings > Extended Function > Remote Zone-Channel)
11 EXTERNAL PORTS
11.2 D-sub 25-pin Connector
Common FUNC (K, F)/Ver 2.20 224
