Kenwood NX-5200K3 Common Function Reference

Connection Status Configuration Status Audio Output Pattern
External
Speaker
Bluetooth-
compatible
Device
External Speaker Bluetooth Speaker
Internal
Speaker
External
Speaker
Bluetooth-
compatible
Device
Connected Connected
Internal + External (Mobile only) Only No output No output Output
Off Both (Bluetooth+Radio) (Mobile only) Output No output Output
On Both (Bluetooth+Radio) (Mobile only) No output Output Output
Internal + External (Mobile only) Both (Bluetooth+Radio) (Mobile only) Output Output Output
Configuration using KPG-D1/ D1N
Assigning functions to the PF keys on the transceiver ( Transceiver Settings > Key Assignment)
Determining the Speaker to Emit by Linking with the Microphone Hook (Off-hook
Speaker Revert)
Supported Models: Mobile
Off-hook Speaker Revert is
the function to determine whether to use the speaker of the transceiver or the speaker of the
Bluetooth-compatible device connected by Headset Profile, by linking with a microphone on- or off-hook state.
If Off-hook Speaker Revert is enabled, the speaker to emit is determined by the configuration of Bluetooth Speaker
regardless of the microphone on-hook or off-hook state.
If Off-hook Speaker Revert is disabled, the speaker to emit is determined as follows by the microphone hook state and
the configuration of Bluetooth Speaker.
Table 10-12 Off-hook Speaker Revert
Bluetooth Speaker
The
Microphone
Hook Status
Speaker to Emit Audio
When the Microphone Hook Status is
changed
The
Microphone
Hook Status
Speaker to Emit Audio
Off
*1
Off
Transceiver
Off N On
Transceiver
Only
*1
Transceiver Bluetooth-compatible Device
Both (Bluetooth +
Radio)
*1
Transceiver + Bluetooth-
compatible device
Transceiver + Bluetooth-
compatible device
Off
On
Transceiver
On N Off
Transceiver
Only Bluetooth-compatible device Transceiver
Both (Bluetooth +
Radio)
Transceiver + Bluetooth-
compatible device
Transceiver + Bluetooth-
compatible device
*1
The microphone goes to the off-hook state after changing the configuration of Bluetooth Speaker
by pressing the
Bluetooth Speaker key when the microphone is in the on-hook state.
Note
0
This function can be used only when a Bluetooth-compatible device connected by Headset Profile exists.
0
If Off-hook Speaker Revert
is disabled, changing the microphone on- or off-hook state while the audio data is being
played back in Playback Mode pauses the playing.
Configuration using KPG-D1/ D1N
Configuring Off-hook Speaker Revert to be enabled or disabled (
Transceiver Settings > Optional Features >
Optional Features 2 > GPS/Bluetooth > Bluetooth)
10 BLUETOOTH COMMUNICATION
10.7 Switching the Speaker to Emit Audio (Bluetooth Speaker)
Common FUNC (K, F)/Ver 2.20 205
