3.5
Changing the Zone-channel
The Zone-channel can be changed using the Selector (Portable only) or PF keys.
Changing the Zone
The zone can be changed by operating the Selector (Portable only) or PF keys.
Portable
0
Changing the zone according to the number indicated by the pointer of the Selector
Rotating the Selector causes
the transceiver to migrate to the zone having the same number specified by the Selector.
Zones that can be selected are limited to zone 1 to zone 16.
If an unprogrammed zone is selected, “**************” appears on the display.
This behavior can be realized by installing a stopper on the Selector, enabling 16 Zone/Channel Selector, and assigning
the Zone Select function to the Selector. (Refer to Available Functions for the Selector.)
0
Changing the zone regardless of the number indicated by the pointer of the Selector
Rotating the Selector clockwise increases the zone number in steps of 1. Rotating the Selector counterclockwise
decreases the zone number in steps of 1.
If an unprogrammed zone is selected, the zone will be skipped.
This behavior can be realized by disabling 16 Zone/Channel Selector and assigning the Zone Up/ Down function to the
Selector. (Refer to Available Functions for the Selector.)
0
Changing the zone by using the PF key
Pressing the Zone Up key increases the zone number in steps of 1. Pressing the Zone Down key decreases the zone
number in steps of 1.
If “Zone Up (Continuous)” or “Zone Down (Continuous)” is assigned to the Zone Up or Zone Down key, the zone number
is increased or decreased continuously every 200 ms by pressing and holding the Zone Up or Zone Down key.
If an unprogrammed zone is selected, the zone will be skipped.
0
Changing the zone by using the Lever switch
Positioning the Lever switch to the [A] position migrates the transceiver to the zone configured in Zone A (Lever A
Position).
Positioning the Lever switch to the [B] position migrates the transceiver to the zone configured in Zone B (Lever B
Position).
Note
The operation for changing the zone changes depending on the configuration in Rollover/
End Stop. (Refer to Rollover/
End Stop.)
Mobile
Pressing the Zone Up key increases the zone number in steps of 1. Pressing the Zone Down key decreases the zone
number in steps of 1. KCH-20R (Featured Panel) is operated by using the Selector just as Portable.
If “Zone Up (Continuous)” or “Zone Down (Continuous)” is assigned to the Zone Up or Zone Down key, the zone number
is increased or decreased continuously every 200 ms by pressing and holding the Zone Up or Zone Down key.
If an unprogrammed zone is selected, the zone will be skipped.
Note
The operation for changing the zone changes depending on the configuration in Rollover/
End Stop. (Refer to Rollover/
End Stop.)
3 BASIC OPERATIONS
3.5 Changing the Zone-channel
Common FUNC (K, F)/Ver 2.20 40
