Kenwood NX-5200K3 Common Function Reference

Configuration using KPG-D1/ D1N
0
Assigning functions to the PF keys on the transceiver ( Transceiver Settings > Key Assignment)
0
Configuring 16 Zone/Channel Selector to be enabled or disabled ( Transceiver Settings > Key Assignment >
Top/Side)
0
Configuring Zone A (Lever A Position) ( Transceiver Settings > Key Assignment > Zone Select)
0
Configuring Zone B (Lever B Position) ( Transceiver Settings > Key Assignment > Zone Select)
Changing the Channel
The channel can be changed using the Selector (Portable only) or PF keys.
Portable
0
Changing the channel according to the number indicated by the pointer of the Selector
Rotating the Selector
causes the transceiver to migrate to the channel having the same number specified by the
Selector. Channels that can be selected are limited to channel 1 to channel 16.
If an unprogrammed channel is selected, “**************” appears on the display.
This behavior can be realized by installing a stopper on the Selector, enabling 16 Zone/Channel Selector, and assigning
the Channel Select function to the Selector. (Refer to Available Functions for the Selector.)
0
Changing the channel regardless of the number indicated by the pointer of the Selector
Rotating the Selector clockwise increases the channel number in steps of 1. Rotating the Selector counterclockwise
decreases the channel number in steps of 1.
If an unprogrammed channel is selected, the channel will be skipped.
This behavior can be realized by disabling 16 Zone/Channel Selector and assigning the Channel Up/ Down function to
the Selector. (Refer to Available Functions for the Selector.)
0
Using the PF keys
Pressing the Channel Up key increases the channel number in steps of 1. Pressing the Channel Down key decreases
the channel number in steps of 1.
If “Channel Up (Continuous)” or “Channel Down (Continuous)” is assigned to the Channel Up or Channel Down key, the
channel number increases or decreases continuously at 200 ms intervals by pressing and holding the Channel Up or
Channel Down key.
If an unprogrammed channel is selected, the channel will be skipped.
Note
The operation for changing the channel changes depending on the configuration in Rollover/ End Stop. (Refer to
Rollover/ End Stop.)
Mobile
Pressing the Channel Up key
increases the channel number in steps of 1. Pressing the Channel Down key decreases the
channel number in steps of 1. KCH-20R (Featured Panel) is operated by using the Selector just as Portable.
If “Channel Up (Continuous)” or “Channel Down (Continuous)” is assigned to the Channel Up or Channel Down key, the
channel number increases or decreases continuously at 200 ms intervals by pressing and holding the Channel Up or
Channel Down key.
If an unprogrammed channel is selected, the channel will be skipped.
Note
The operation for changing the channel changes depending on the configuration in Rollover/ End Stop. (Refer to
Rollover/ End Stop.)
3 BASIC OPERATIONS
3.5 Changing the Zone-channel
Common FUNC (K, F)/Ver 2.20 41
CONTENTS INDEX
