Kenwood NX-5200K3 Common Function Reference

Icons Description
0
Intercom Icon
Appears when Intercom is enabled in a Dual Control Head structure for Mobile.
0
Lone Worker Icon
Appears when the Lone Worker is enabled.
0
Activity Detection Icon (Portable only)
Appears when the Activity Detection is enabled.
0
OVCM Icon
Appears when OVCM is enabled.
0
Compander Icon
Appears when the Compander is enabled.
0
OST Icon
Appears when the OST is enabled.
0
Auto Recording Icon
Appears while the Auto Recording is executing.
0
Key Lock Icon
Appears when the Key Lock is enabled.
5.10
Displaying the Signal Strength (Signal Strength Indicator)
Signal Strength Indicator
can be used to display the signal strength of the received signal.
The RSSI icon indicating the signal strength appears in the following manner depending on the signal level of the received
signal.
Table 5-3 Signal Strength Indicator
Icons Status Signal Strength
High Above -80 dBm
Medium -95 dBm to -80 dBm
Low -110 dBm to -95 dBm
Very weak
With a carrier
less than -110 dBm
Disabled No signal No carrier
Blinking: Outside of the communication area
(P25 Trunking/ NXDN Trunking system only)
-
Note
The signal strength references are rough indicators of room temperature.
Configuration using KPG-D1/ D1N
Configuring Signal Strength Indicator to be enabled or disabled ( Transceiver Settings > Optional Features >
Optional Features 1 > Display)
5 INDICATION AND DISPLAY
5.9 The Icons on the LCD
Common FUNC (K, F)/Ver 2.20 99
