If the selected channel number does not satisfy the conditions for acquiring
a
control channel, the transceiver enters the Out of Service state, and then
the RSSI icon blinks. In this case, the site number or site name does not
appear.
Maintenance 1
12 : 34
A
M
RSSI Level dBm
Site
-
BackSelect
Note
0
In an NXDN Trunking system, if the transceiver is in Failsoft mode, the channel number of the Failsoft channel appears.
In this case, the site number or site name does not appear. In a P25 Trunking system, if the transceiver is in Failsoft
mode, the channel number and site number or the site name does not appear.
0
If the transceiver is in a Roaming System by using the SKF for roaming in the Multi-System Roaming function, Failsoft
does not function.
0
In a P25 Trunking or NXDN system, pressing the PTT switch while the transceiver is in Maintenance Display Mode starts
a Group Call with the Maintenance Display Mode displayed. If the transceiver migrates to a traffic channel, the display of
the channel number is changed to the channel number of the traffic channel. If the transceiver receives a Group Call while
in Maintenance Display Mode, the transceiver receives the Group Call with the Maintenance Display Mode displayed in
the same way.
0
The PTT switch can be used even if the transceiver is in Maintenance Display Mode. However, in a P25 Trunking or
NXDN Trunking system, the PTT switch cannot be used if the transceiver is in the Out of Service state.
0
While this function is in use, Battery Saver is disabled. (Portable only)
0
In an NXDN Trunking system, the display is renewed at intervals of 1 frame.
0
If the transceiver enters Maintenance Display Mode while the Site Lock is enabled, the Site Lock is temporarily disabled.
In this case, the Site Lock is enabled when the transceiver exits Maintenance Display Mode.
0
If the transceiver enters Maintenance Display Mode while the transceiver is outside of the communication area, the
channel number retained in the transceiver appears.
0
When the transceiver is in Maintenance Display Mode, the ID display in Caller ID Display of NXDN or P25 and the
message display when a Status/ Short Message is received are not displayed.
0
Maintenance Display does not function in a Multi RF Deck/ Multi Control Head structure for Mobile.
Configuration using KPG-D1/ D1N
Assigning functions to the PF
keys on the transceiver (
Transceiver Settings > Key Assignment)
4 TRANSMISSION/ RECEPTION
4.5 Displaying the Signal Strength Level (RSSI Level, BER) (Maintenance Display)
Common FUNC (K, F)/Ver 2.20 87
