A Key Beep A (1 beep) sounds from the transceiver and pairing starts. An LED flashes blue during pairing.
12 : 34
A
M
Connecting
Find Device 1
If the selected Bluetooth-compatible device is already registered in the transceiver, the connection process starts by
HSP Connection without pairing occurring. Proceed to step 5.
If the selected Bluetooth-compatible device is not registered in the transceiver, the transceiver checks whether the
Bluetooth-compatible device supports Secure Simple Pairing. The operation procedure differs as follows according
to the check results. (Refer to About Authentication.)
0
If Secure Simple Pairing is not supported
The following screen appears. Proceed to step 3.
12 : 34
A
M
Input PIN Code
Find Device 1
0
If Secure Simple Pairing is supported
The behavior differs as follows depending on whether an input function and display function are available for the
Bluetooth-compatible device:
0
No input function/ no display function
Pairing continues. The display does not change. Proceed to step 5.
0
Input function available/ no display function
Pairing
cannot occur because the transceiver cannot authenticate this Bluetooth-compatible device. In this case,
pairing ends.
0
Input function available/ display function available
The following screen appears. Proceed to step 4.
12 : 34
A
M
Passkey
123456
Find Device 1
OK
10 BLUETOOTH COMMUNICATION
10.3 Registering and Connecting a Bluetooth-compatible Device to the Transceiver (Pairing/ HSP Connection)
Common FUNC (K, F)/Ver 2.20 184
