Kenwood NX-5200K3 Common Function Reference

If the Bluetooth-compatible device having an address configured in Define Bluetooth Device
is already registered
in the transceiver, the connection process starts by HSP Connection without pairing occurring. Proceed to step 3.
If the Bluetooth-compatible device having an address configured in Define Bluetooth Device is not registered in
the transceiver, the transceiver checks whether the Bluetooth-compatible device supports Secure Simple Pairing.
The operation procedure differs as follows according to the check results. (Refer to About Authentication.)
0
If Secure Simple Pairing is not supported
The transceiver checks whether the Fixed PIN matches. If the Fixed PIN matches, pairing continues. Proceed to step 3.
If the Fixed PIN does not match, pairing cannot occur because the transceiver cannot authenticate this Bluetooth-
compatible device. In this case, pairing ends.
0
If Secure Simple Pairing is supported
The behavior differs as follows depending on whether an input function and display function are available for the
Bluetooth-compatible device having an address configured in Define Bluetooth Device:
0
No input function/ no display function
Pairing continues. The display does not change. Proceed to step 3.
0
Input function available/ no display function
Pairing cannot occur because the transceiver cannot authenticate this Bluetooth-compatible device. In this case,
pairing ends.
0
Input function available/ display function available
The following screen appears. Proceed to step 2.
12 : 34
A
M
Passkey
123456
LMIC
OK
Note
0
Pressing
the Bluetooth Connect / Disconnect key while Bluetooth is turned Off causes Bluetooth to automatically
turn On, and then pairing starts.
0
If the Bluetooth device address of the transceiver is configured in Define Bluetooth Device, pressing the
Bluetooth Connect / Disconnect key sounds a Key-entry Error Tone (1 beep) and the transceiver does not
respond at all.
2
Check whether the Passkey displayed on the transceiver and the Passkey displayed on the Bluetooth-
compatible device are the same.
12 : 34
A
M
Passkey
123456
LMIC
OK
If the Passkeys match:
Press the Menu ([Q]) or [*]
key.
A Key Beep A (1 beep) sounds from the transceiver and pairing continues. Proceed to step 3.
Menu Zone +
Zone 1
Channel 1
12 : 34
A
M
Connecting
10 BLUETOOTH COMMUNICATION
10.3 Registering and Connecting a Bluetooth-compatible Device to the Transceiver (Pairing/ HSP Connection)
Common FUNC (K, F)/Ver 2.20 187
