Function Name Description
AUX Output Status
Message 1 to AUX
Output Status
Message 3
The status of these ports are changed when the transceiver receives a FleetSync, NXDN, or DMR
Status Message. The transceiver alternates the status of the AUX Output port (High to Low or Low
to High) when the received Status Message matches the Status number preconfigured for the
port.
Two statuses (High N Low, and Low N High) can be configured for each port of AUX Output
Status Message 1 to AUX Output Status Message 3 by using KPG-D1/ D1N. These ports are
usually used to remotely control the transceiver by connecting an external device to the AUX
Output port.
Also, the port status can be retained even if the transceiver is turned OFF.
Note
This function is disabled when the transceiver receives a response status to a PC command
(AUX
Status Request Transmission). However, in a DMR Conventional system, this function is
enabled even if the transceiver receives a response status to a PC command (AUX Status
Request Transmission).
Encryption
If the Encryption function (AES, DES, or bit scramble) is configured for a received signal, the output
port is active while receiving the signal. Otherwise, this port is inactive.
Selected RF Deck
In a Multi RF Deck system, the output port is active for the Selected RF Deck. The port is inactive
for the Unselected RF Deck.
Digital Mode
For a Conventional Channel (Analog/ NXDN/ DMR/ P25):
The output port is active if a channel with “NXDN”, “DMR”, or “P25” configured in Channel
Type is selected.
The output port is inactive if a channel with “Analog” configured in Channel Type is selected.
For an NXDN Trunking/ P25 Trunking/ LTR Trunking system:
The output port is active if a channel in an NXDN Trunking system or P25 Trunking system is
selected.
The output port is inactive if a channel in an LTR Trunking system is selected.
If “Mixed” is configured in Channel Type:
The transceiver behaves as follows according to the configuration in Transmit Mode (Analog
or Digital):
Analog:
0
The output port is inactive when Signaling Reset Timer (or Auto Reset Timer) is not
activated.
0
The output port is active if the transceiver receives a digital signal, Signaling Reset
Timer
or Auto Reset Timer is activated, and the transceiver transmits a digital signal.
0
The output port is inactive if the time configured in Signaling Reset Timer (or Auto Reset
Timer) elapses, and the transceiver transmits an analog signal.
Digital:
0
The output port is active when Signaling Reset Timer (or Auto Reset Timer) is not
activated.
0
The output port is inactive if the transceiver receives an analog signal, Signaling Reset
Timer or Auto Reset Timer is activated, and the transceiver transmits an analog signal.
0
The output port is active if the time configured in Signaling Reset Timer (or Auto Reset
Timer) elapses, and the transceiver transmits a digital signal.
Out of Range
The output port is active if the transceiver is in the Out of Range state in an NXDN Trunking system
or
P25 Trunking system. If the transceiver is in the state other than Out of Range, the output port
is inactive.
Configuration using KPG-D1/ D1N
0
Assigning functions to the AUX Output port ( Transceiver Settings > Extended Function > AUX)
0
Configuring LOK Logic Signal ( Transceiver Settings > Extended Function > AUX > AUX Output)
0
Configuring Data Override ( Extended Function > AUX > AUX Input)
11 EXTERNAL PORTS
11.2 D-sub 25-pin Connector
Common FUNC (K, F)/Ver 2.20 220
