Kenwood NX-5200K3 Common Function Reference

0
Control Head
By
pressing the Bluetooth Speaker key, or by pressing the Menu key to enter Menu Mode and then executing “Bluetooth
Speaker”, the configuration in Bluetooth Speaker can be changed.
In the following diagram, a Bluetooth speaker is connected to all Control Heads. If “Both” is configured in Bluetooth
Speaker, the pattern of emitting audio when the audio is simultaneously received is as follows:
Audio Reception
①
Audio Reception
②
Audio Reception
③
KRK-15B
RF Deck 1
(Selected)
KRK-15B
RF Deck 2
(Unselected)
KRK-15B
RF Deck 3
(Unselected)
Figure 16-76 Pattern of Emitting Audio (Control Head)
16 MULTI RF DECK/ MULTI CONTROL HEAD
16.16 Bluetooth Communication
Common FUNC (K, F)/Ver 2.20 314
