Kenwood NX-5200K3 Common Function Reference

7
Write the FPU data.
The FPU data for Triple RF Deck/ Dual Control Head is written in a Multi RF Deck system. Always write the FPU
data in a Multi RF Deck system. Refer to “Configuration in KPG-D1/ D1N if RF Decks Are Switched” for writing
configuration data.
Control Head
2
RF Deck 3
KRK-15B
RF Deck 2
KRK-15B
Control Head
1
RF Deck 1
KRK-15B
KPG-D1/ D1N
Figure 17-44 Triple RF Deck/ Dual Control Head (FPU Setting)
Note
If “FIRM MISMATCH” is displayed on the screen of the Control Head, start again from step 6.
17 STRUCTURING A MULTI RF DECK/ MULTI CONTROL HEAD
17.3 Replacing an RF Deck/ Control Head
Common FUNC (K, F)/Ver 2.20 359
