Sidetone
Tone Name
Pattern
Reference
Proceed Tone
3 beeps
1000 Hz
(20 ms)
Sidetone
PTT Proceed Tone
VOX Proceed Tone
1 beep
1550 Hz (30 ms)
Sidetone
PTT ID Sidetone
4 beeps
1210 Hz
(30 ms)
1630 Hz
(30 ms)
1210 Hz
(30 ms)
1630 Hz
(30 ms)
Sidetone
0
Alert Tone
Tone Name
Pattern
Reference
Transmit Clear Alert
Tone
1 beep
1477 Hz
(50 ms)
Alert Tone
Site Trunking Alert
2 beeps
622 Hz
(100 ms)
932 Hz
(100 ms)
Alert Tone
Ack Wait Enter Tone
7 beeps
770 Hz
(30 ms)
Alert Tone
Emergency Indicator
Alert Tone
1 beep
880 Hz
(150 ms)
Alert Tone
0
Volume Level Tone
Tone Name
Pattern
Reference
Volume Key Tone
1 beep
1630 Hz
(50 ms)
Volume Level Tone
Fixed Volume Key
Tone
1 beep
1630 Hz
(50 ms)
Volume Level Tone
21 BEEP LIST
Common FUNC (K, F)/Ver 2.20
438
