About This Manual
This In-depth manual describes the functions of the transceiver (NX-5200/ NX-5300/ NX-5400/ NX-5700/ NX-5800/
NX-5900) used in common in each of an analog, P25, NXDN, and DMR systems.
This document is created for the product having the following design specifications.
Item Specifications How to Verify
Market Code K, F
Printed or labeled on the packaging and the model name plate on the
transceiver.
Firmware Version of
the Transceiver
2.20.00
Can be viewed in the Transceiver Information dialog box of KPG-D1/ KPG-
D1N. Or, firmware version of the transceiver can be viewed by the following
ways:
Portable transceiver/ KCH-21R (Handheld Control Head):
Turning
the transceiver ON while pressing and holding the Side 3 key of the
transceiver displays the firmware version on the display.
Mobile transceiver (KCH-19 (Basic Panel)/ KCH-20R (Featured Panel)):
Turning the transceiver ON while pressing and holding the [+] key causes the
firmware version to appear on the display.
Common to Portable and Mobile:
Turning the transceiver ON while pressing and holding the Menu ([Q]) key
causes the transceiver to display Radio Mode Selection. Then, if “Transceiver
Info” is selected and the Menu ([Q]) key is pressed, the transceiver enters
Transceiver Information Mode, and then the firmware version can be viewed.
Version of KPG-D1/
KPG-D1N
V 2.20
Can be viewed in the About KPG-D1 dialog box or About KPG-D1N dialog
box of KPG-D1/ KPG-D1N.
K, F: Designed for the North American markets.
Also, the following Radio Feature License is required to use the functions described in this manual:
0
P25 system
Function Name Radio Feature License
P25 Conventional
*1
KWD-5100CV
P25 Phase 1 Trunking KWD-5101TR
P25 Phase 2 Trunking KWD-5102TR
P25 OTAP
*2
KWD-5104AP
*1
Implemented before factory shipment for the F-type transceiver.
*2
Implemented before the factory shipment for the K- and F-type transceiver.
0
NXDN system
Function Name Radio Feature License
NXDN Conventional
*1
KWD-5200CV
NXDN Type-C Trunking
*2
KWD-5201TR
NXDN OTAP
*1
KWD-5204AP
*1
Implemented before the factory shipment for the K- and F-type transceiver.
*2
Implemented before the factory shipment for the K-type transceiver.
About This Manual
Common FUNC (K, F)/Ver 2.20 viii
