Keysight B2980B Series User Manual

Keysight B2980B User’s Guide, Edition 1 257
Function Details
Initial Settings
Voltage sweep points 1
Voltage sweep start 0 V
Voltage sweep stop 0 V
Voltage list points 1
Voltage list values 0 V
Sweep direction UP
Double sweep OFF
Sweep ranging BEST
Continuous triggered source ON
Measure function Current and voltage
Automatic ranging speed Normal
Aperture mode Medium
Auto aperture ON
Aperture time 0.1 PLC
Voltage measure range mode AUTO
Voltage measure range limit 2 V
Voltage measure range 2 V
Current measure mode AUTO
Current measure range limit 2 pA
Current measure range 2 A
Charge measure range mode AUTO
Charge measure range limit 2 nC
Charge measure range 20 nC
Charge measure auto discharge OFF
Setup item Power on Reset
