Keysight B2980B User’s Guide, Edition 1 259
Function Details
Initial Settings
Table 5-11 LXI Trigger Events Initial Settings
ARM delay time 0 s
ARM bypass OFF
Trigger count 1
Trigger source AINT
Trigger timer 100 s
Trigger delay time 0 s
Trigger bypass OFF
External trigger output EXT1
External trigger output (LAN) LAN0-7 (all)
External trigger output enable OFF
Setup item Power on Reset
Event domain 0
LAN event “WaitingForAcquireArm1”,
“WaitingForTransitionArm1”,
“WaitingForAcquireTrigger1”,
“WaitingForTransitionTrigger1”,
“Measuring1”, “Settling1”
Delay time 0
Input/output filter string “ALL:5044”
Input/output status OFF
Input detection RISE
Output drive OFF
Output slope Positive
Output source “”
Setup item Power on Reset
