Kollmorgen MMC Smart Drive - Page 123

Kollmorgen - December 2011 121
MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
Figure 5-8: 500 W Narrow Drive (-DN) - Front View
2.96 in
(75.18 mm)
2.49 in
(63.25 mm)
1.49 in
(37.85 mm)
.50 in
(12.70 mm)
9.69 in
(246.13 mm)
H
E
A
T
S
I
N
K
