120 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
5.4 Dimensions for 230V MMC Smart Drive
This section contains dimensional information on the narrow width (-DN) Digital MMC-
SD drive, the standard width (-D) Digital MMC-SD drive, and the Analog Interfaced
drive (no letter suffix). Use this information to determine mounting hole locations on
the drive panel.
When locating the drive on the panel, observe the clearance requirements found in
Table 3-1 on page 21. Mount the drive to the panel with #10 bolts and #10 star
washers (to ensure proper ground connection).
DC Input Power Specifications (24VDC)
Input Voltage Range 24 VDC +15% -10%
Typical Input Current 375 mA
Typical Input Wattage 9 W
Inrush Current 1.5 A for 10 ms
Relay Contact for Motor Mechanical Brake
Rating (resistive load)
Nominal switching
capacity
24 VDC
Maximum
switching power
831 VA
Maximum
switching voltage
250 VAC / 100 VDC
Maximum
switching current
5 A (AC) / 2.5 A (DC)
Energy Absorbtion Specifications
DC Bus Capacitance
(Internal)
1410 μF 1880 μF
Bus overvoltage
threshold
420 VDC
Joules available for energy absorption
230V motor w/115V
line input
94 joules 126 joules
230V motor w/230V
line input
38 joules 51 joules
a. All Digital 3-phase drives support BiSS encoders
