Kollmorgen - December 2011 233
MMC Smart Drive Hardware Manual - S200-DLS DRIVE
8.3 Specifications - S200-DLS Drive
The S200-DLS consists of a Base Unit with an S200 Digital Link Option Card installed.
The combination of the two components is the S200-DLS Drive. The Base Unit is
described in detail in Kollmorgen’s S200 Base Unit Reverence Manual, P/N M-SM-
200-01, which can be found at http://www.kollmorgen.com/website/com/eng/products/
drives/ac_servo_drives/s200_manuals.php. Please refer to the S200 Base Unit
Reference Manual for Base Unit Specifications, Mounting information, Wiring
information, etc. The Base Unit has the same Part Number as the Digital Link version,
except that the -DLS is replaced with -VTS. For example, a S20360-DLS consists of
an S20360-VTS Base Unit and an S200 Digital Link Option Card.
Any data contained in this manual takes precedence over conflicting data found in the
Base Unit manual.
Part Numbers
S20260-DLS Input = 120/240VAC, Output = 1.5A RMS continuous
S20360-DLS Input = 120/240VAC, Output = 3A RMS continuous
S20660-DLS Input = 120/240VAC, Output = 6A RMS continuous
S21260-DLS Input = 120/240VAC, Output = 12A RMS continuous
S22460-DLS Input = 120/240VAC, Output = 24A RMS continuous
S20330-DLS Input = 20-90VDC, Output = 3A RMS continuous
S20630-DLS Input = 20-90VDC, Output = 6A RMS continuous
Drive I/O Port DC Inputs
Configuration
•4 optically isolated 24V DC inputs
•Active high
•Sink or source
Guaranteed On 15 VDC
Guaranteed Off 5 VDC
Time delay on 1 ms max.
Time delay off 1 ms max.
Input voltage Nominal 24 VDC, maximum 30 VDC
