112 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
6. The process is repeated starting with step 1 above as required
If during step 3 above, the user-supplied external circuitry removes 24Vdc from the
"EN" input (usually due to a safety violation on the equipment being controlled), the
drive will fault, and the motor will coast to a stop. The drive must be powered off and
back on to remove the fault condition.
5.2.1.1.2 "EN" operation on non-Safe-off Drives
If the Drive does not include the Safe-off feature, regardless of the sequence of
operation, if the "EN" ever loses 24Vdc, the drive faults, and the motor coasts to a
stop. The drive must be powered off and back on to remove the fault condition.
5.2.2 Power Connector
The Power Connector consists of a non-pluggable 9-pin screw-terminal block, and
provides connection to the incoming AC power and the motor that is being controlled
by the Drive.
ADDITIONAL SHUNT RESISTOR INFORMATION
Refer to section 4.5 on page 52 for instructions on choosing, mounting, and
connecting Shunt Resistors available from Kollmorgen.
