Kollmorgen MMC Smart Drive

Kollmorgen - December 2011 143
MMC Smart Drive Hardware Manual - 460V 3 PHASE MMC SMART DRIVE NEXTGEN
6.1.4.2 Feedback Port (F1/F2) to Motor Cables
Cables are available that allow easy connection between the F1 & F2 Feedback Ports
and various Kollmorgen motors. These cables are outlined in Table 6-11. The wiring
diagram for each cable is located in the indicated Table. For information on Non-Flex
versus Hi-Flex cables, refer to section 9.1 on page 235.
Table 6-11: F1/F2 to AKM/DDR Motor Cables
a
a. "XX" in the above table denotes the length of the cable, in meters. Standard
"XX" values are 01, 03, 06, 09, and 12. Hi-Flex cables are available in addi-
tional lengths. Consult Kollmorgen for more information.
Feedback Non-Flex P/N Hi-Flex P/N Wiring Diagram
Incremental
Encoder
Not Available CF-CB7374N-XX-0
Table 6-12 on
page 144
Endat/BiSS
b
b. Feedback type not available on F2
VF-SB4474N-XX CF-SB7374N-XX-0
Table 6-13 on
page 145
Resolver
b
VF-RA2474N-XX CF-RA2574N-XX-0
Table 6-14 on
page 146
SFD VF-DA474N-XX CF-DA0374N-XX-0
Table 6-15 on
page 147
