9.5 LSM/MSM Motor Power Cables
This section describes flying-lead wiring assemblies that can be used connect the
Motor Power signals from the drive to an LSM/MSM motor. Each assembly consists
of the indicated length and gauge of Hi-Flex cable pre-wired to the indicated LSM/
MSM Motor power connector.
Table 9-4: LSM/MSM Motor Power Flying-lead Cables
Wire Gauge Figure Wire Length Hi-Flex P/N
16AWG
Size 1 in
Table 9-5 on
page 242
1 M (3.3 ft) M.1302.1114
3 M (9.8 ft) M.1302.1115
6 M (19.7 ft) M.1302.1116
9 M (29.5 ft) M.1302.1117
15 M (49.2 ft) M.1302.1118
14AWG
Size 1 in
Table 9-5 on
page 242
1 M (3.3 ft) M.1302.1119
3 M (9.8 ft) M.1302.1130
6 M (19.7 ft) M.1302.1131
9 M (29.5 ft) M.1302.1132
15 M (49.2 ft) M.1302.1133
12AWG
Size 1.5.1 in
Table 9-5 on
page 242
1 M (3.3 ft) M.1302.1134
3 M (9.8 ft) M.1302.1135
6 M (19.7 ft) M.1302.1136
9 M (29.5 ft) M.1302.1137
15 M (49.2 ft) M.1302.1139
10AWG
Size 1.5.1 in
Table 9-5 on
page 242
1 M (3.3 ft) M.1302.1140
3 M (9.8 ft) M.1302.1142
6 M (19.7 ft) M.1302.1143
9 M (29.5 ft) M.1302.1144
15 M (49.2 ft) M.1302.1145
