Kollmorgen - December 2011 71
MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
5 230V 1/3 Phase MMC Smart Drive
The 230V MMC Smart Drive is available in both analog and digital interfaced versions,
with power ratings from .5kW through 3kW. This section describes these drives in
detail.
The following 230V MMC Smart Drive are available:
• Single Phase analog and digital interfaced versions, with power ratings of .5kW,
1kW, and 2kW.
• Three Phase analog and digital interfaced versions, with power ratings of .5kW,
1kW, 2kW, 3kW (digital interfaced only).
Features include:
• 230V, Single Phase drives available with power ratings of .5kW, 1kW, and 2 kW
• 230V, Three Phase drives available with power ratings of .5kW, 1kW, 2 KW, and 3
kW
• Can also operate on Single Phase power
• Built-in Regen circuitry (requires external Regen resistor)
• Optional Safe-off feature
• Drive firmware in user upgradeable Flash memory
• Serial port for communications with PC-resident PiCPro
• Internal switch to control a mechanical brake
• Green Power LED and yellow Diagnostic LED
• Motor feedback types include incremental encoder, high resolution encoder, and
resolver
• Eight General Purpose 24VDC Inputs
• Four General Purpose 24VDC outputs
• +10V command input (Analog Interfaced MMC-SD only)
• Digital Link digital connections (Digital MMC-SD only)
• Optional MMC-SD Control (for Digital MMC-SD only)
• UL Listed and CE Marked.
