MMC Smart Drive Hardware Manual - MOTOR CABLES & CONNECTORS
9.4 LSM/MSM Motor Connector Kits
This section describes LSM/MSM Motor mating connectors for use in constructing
custom cables using user-supplied cable. Available connectors are described in
Table 9-3.
Table 9-3: Connector Kits for LSM/MSM Motors
Function Wire Size Part Number Figure
Feedback 18-28AWG M.1302.0500
Feedback 18-28AWG M.1302.0510
Power/Brake 14-16AWG M.1302.0479
Power/Brake 12AWG M.1302.8755
Power/Brake 12-14AWG
M.1302.1998
Power/Brake 8-10AWG
M.1302.2354
Power/Brake 6AWG M.1302.7492
Consult Factory
Power/Brake 4AWG M.1302.7493
Fan 16AWG M.1302.6219
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
B
A
C
D
3
1
4
+
V
U
1
2
W
1
2
4
3
5
6
