156 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 460V 3 PHASE MMC SMART DRIVE NEXTGEN
6.2.3.1 Motor/Brake Cables
Cables are available that allow easy connection to the between the Motor Power
connector and Kollmorgen AKM/DDR motors. These cables are outlined in Table 6-
22. For a detailed description of these cables, refer to the Kollmorgen "AKD/S700
Accessories Manual" which can be found at www.kollmorgen.com. For information on
Non-Flex versus Hi-Flex cables, refer to section 9.1 on page 235.
6.2.3.2 Motor Chokes
If a motor cable over 25 meters is used, a Motor Choke must be installed. These
chokes are outlined in Table 6-23. For a detailed description of these chokes, refer to
the Kollmorgen "AKD/S700 Accessories Manual" which can be found at
www.kollmorgen.com.
Table 6-22: Motor Connector to AKM/DDR Motor Cables
a
a. "XX" in the above table denotes the length of the cable, in meters. Standard
"XX" values are 01, 03, 06, 09, and 12. Hi-Flex cables are available in additional
lengths. Consult Kollmorgen for more information.
Drive
Non-Flex P/
N
Non-Flex (w/
brake) P/N
(a)
Hi-Flex P/N
(a)
Hi-Flex (w/
brake) P/N
(a)
MMC-SDN-
1.8-460-D
MMC-SDN-
3.6-460-D
VP-
507BEAN-XX
VP-508CFAN-
XX
CP-507CCAN-
XX
CP-507CDAN-
XX
MMC-SDN-
7.2-460-D
VP-
508CEAN-XX
VP-508CFAN-
XX
CP-507CCAN-
XX
CP-507CDAN-
XX
MMC-SDN-
14.4-460-D
VP-
508DEAN-XX
VP-508DFAN-
XX
CP-508EBDN-
XX
CP-508EBDN-
XX
Table 6-23: Motor Chokes
Drive Choke Part Number
MMC-SDN-1.8-460-D
MMC-SDN-3.6-460-D
3LYN-06
MMC-SDN-7.2-460-D 3LYN-14
MMC-SDN-14.4-460-D 3LYN-24
