Kollmorgen MMC Smart Drive

198 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 460V 3-PHASE MMC SMART DRIVE
7.4.4 Physical/Electrical Data for 460V Size 3 Smart Drives
Model
MMC-SD-
12.0-460
(-D)
MMC-SD-
16.0-460
(-D)
MMC-SD-
24.0-460
(-D)
MMC-SD-
30.0-460-D
Part Numbers
Analog
Digital, no BiSS
Digital, BiSS
M.1302.5098
M.1302.8138
M.3000.0469
M.1302.5099
M.1302.8139
M.3000.0470
M.1302.5100
M.1302.8140
M.3000.0471
M.3000.0545
N/A
M.3000.0021
Physical
Weight
35 lbs.
Electrical Specifications
AC Input Specifications
Wire Size
0.5mm
2
to 10mm
2
(20-6AWG)
Screw Torque 1.56 Nm
Input Configuration
Industrial system with direct low impedance earthed star point
(TN or TT mains). Do not use with IT mains or corner grounded
delta.
Inductance 2.4% (min) to 4% (max)
Nominal Input Power 13.3kVA 16.8kVA 26.3 kVA 36.7 kVA
Input Voltage 207-528 VAC (400 VAC nominal), 3 Phase
Input Frequency 47-63Hz
Nominal Input
Current
16.7A RMS 21.1A RMS 33.1A RMS 44.0A RMS
NOTE: Nominal Input Current is specified for nominal input voltage of 460 VAC.
Approximate Current for input voltages between 400 and 480 VAC = (listed current) x
460/input voltage
Maximum Inrush
Current
32.2A RMS 39.2A RMS 61.8A RMS tbdA RMS
Power Loss 300W 390W 600W 840W
