54 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - SYSTEM POWER DEVICES
4.5.2 Mounting External Shunts
This section describes the mounting requirements for External Shunts available from
Kollmorgen.
Table 4-12: Shunt Resistors
For Drive
a
Shunt Resistor Module
Part
Number
MMC-SD-0.5-230
MMC-SD-1.0-230
MMC-SD-2.0-230
MMC-SD-3.0-230
For Single Phase Drives:
100Ω, 300W, 600V, Dynamic
M.1015.7046
For Three Phase Drives:
30Ω, 300W Cont. Power. 215mm(L) x
60mm(W) x 30mm(H)
M.3000.0503
MMC-SD-1.3-460
MMC-SD-2.4-460
145Ω, 450W Cont. Power, 5.4kW Peak Pow-
er, 820 V, 240 sec. Time Constant, 121 mm
x 93 mm x 605 mm
M.1302.7048
130Ω, 150W, Reduced Size Panel Mount M.3000.0504
MMC-SD-4.0-460
95Ω, 700W Cont. Power, 8kW Peak Power,
820 V, 250 sec. Time Constant, 121 mm x 93
mm x 705 mm
M.1302.7049
95Ω, 300W, Reduced Size Panel Mount M.3000.0505
MMC-SD-6.0-460
MMC-SD-8.0-460
50Ω, 1400W Cont. Power, 17kW Peak Pow-
er, 850V, 250 sec. Time Constant, 130 mm x
182 mm x 710 mm
M.1302.7060
50Ω, 500W, Reduced Size Panel Mount M.3000.0506
MMC-SD-12.0-460
MMC-SD-16.0-460
25Ω, 2800W Cont. Power, 32kW Peak Pow-
er, 850V, 60 sec. Time Constant, 171 mm x
430 mm x 550 mm
M.1302.7061
25Ω, 800W, Reduced Size Panel Mount M.3000.0507
MMC-SD-24.0-460
MMC-SD-30.0-460
MMC-SD-42.0-460
MMC-SD-51.0-460
MMC-SD-65.0-460
18Ω, 3900W Cont. Power, 70kW Peak Pow-
er, 850V, 70 sec. Time Constant, 180 mm x
445 mm x 490 mm
M.1302.7063
18Ω, 1200W, Reduced Size Panel Mount M.3000.0508
MMC-SDN-XXX
See section 6.2.4.2 on page 157 for information on shunt (re-
gen) resistors for use with the SDN drives
a. Drive Model pertains to Analog (no dash suffix) and digital (-D)
