Kollmorgen - December 2011 167
MMC Smart Drive Hardware Manual - 460V 3-PHASE MMC SMART DRIVE
7 460V 3-Phase MMC Smart Drive
The 460V MMC Smart Drive is available in both analog and digital interfaced versions,
with power ratings from 1.3kW through 65kW. This section describes these drives in
detail.
Features include:
• 460V, Three Phase drives available with power ratings of 1.3kW through 65kW
• Drive firmware in user upgradeable Flash memory
• Serial port for communications with PC-resident PiCPro
• Internal switch to control a mechanical brake
• Green Power LED and yellow Diagnostic LED
• Motor feedback types include incremental encoder, high resolution encoder, and
resolver
• Eight General Purpose 24VDC Inputs
• Four General Purpose 24VDC outputs
• +10V command input (Analog Interfaced MMC-SD only)
• Digital Link digital connections (Digital MMC-SD only)
• Optional MMC-SD Control (for Digital MMC-SD only)
• UL Listed and CE Marked.
7.1 Control Section Connectors, Switches, LEDs
The Control Section is located on the right side of the drive, and is identical to the
Control Section on the 230V Smart Drive. Refer to section 5.1 on page 73 for
Information on the connectors, switches, and LEDs located on the Control Section of
the drive.
7.2 Power Section Connectors
The 460V Smart Drive is available in four frame sizes (size 1 through 4). The Power
Section connectors location and function are different among the four frame sizes.
Each frame size is described in detail in the following sections.
7.2.1 Size 1 Power Section Connectors
This section describes in detail the connectors located on the Power Section of the
Size 1 drives.
The functionality and descriptions for the switches and connectors on the Control
Section of the 460V MMC Smart Drives are the same as those on the 230V MMC
Smart Drive. Refer to section 5.1 on page 73 for more information.
