Kollmorgen MMC Smart Drive

166 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 460V 3 PHASE MMC SMART DRIVE NEXTGEN
Figure 6-7: 24 Amp Drive - Front
4.14 in
(105 mm)
.50 in
(12.70 mm)
12.05 in
(306 mm)
.217 in
(5.5 mm)
.217 in
(5.5 mm)
.433 in
(11 mm)
.354 in
(9 mm)
11.50 in
(292 mm)
2.126 in
(54 mm)
(x2)
