7.4.5 Physical/Electrical Data for 460V Size 4 Smart Drives
Model
MMC-SD-
42.0-460-D
MMC-SD-
51.0-460-D
MMC-SD-
65.0-460-D
Part Numbers
Analog
Digital, BiSS
M.3000.0546
M.3000.0022
M.3000.0547
M.3000.0023
M.3000.0548
M.3000.0024
Physical
Weight
59 lbs.
Electrical Specifications
AC Input Specifications
Wire Size
16mm
2
to 50mm
2
(6-0AWG)
Screw Torque 8 Nm
Input Configuration
Industrial system with direct low impedance earthed
star point (TN or TT mains). Do not use with IT mains
or corner grounded delta.
Inductance 2.4% (min) to 4% (max)
Nominal Input Power 48.5kVA 58.2kVA 72.1kVA
Input Voltage 207-528 VAC (400 VAC nominal), 3 Phase
Input Frequency 47-63Hz
Nominal Input Current 58A RMS 72A RMS 95A RMS
NOTE: Nominal Input Current is specified for nominal input voltage of 460
VAC. Approximate Current for input voltages between 400 and 480 VAC =
(listed current) x 460/input voltage
Maximum Inrush
Current
tbdA RMS tbdA RMS tbdA RMS
Power Loss 1080W 1350W 1740W
