MMC Smart Drive Hardware Manual - 460V 3 PHASE MMC SMART DRIVE NEXTGEN
6.3.2 Physical and Electrical Data
Model
MMC-
SDN-1.8-
460-D
MMC-
SDN-3.6-
460-D
MMC-
SDN-7.2-
460-D
MMC-
SDN-
14.4-460-
D
Part Numbers M.3000.1300 M.3000.1301 M.3000.1302 M.3000.1303
Weight, lbs (kg) 6.0 (2.7) 6.0 (2.7) 6.0 (2.7) 11.7 (5.3)
AC Input Specifications
Input Power (kVA) 2.24 4.49 7.65 15.2
Number of Phases
3
a
Input Voltage, VAC
200-480
b
Input Frequency, Hz 47 - 420
Input Current
Amps RMS
3.5 6 12 23
Maximum Inrush
Amps 0-Peak
10 10 10 20
Power Loss, Watts 102 129 153 237
AC Output Specifications
Note: AC Output is specified at an ambient of 0
o
C to 40
o
C (32
o
F to 104
o
F). Derate
output 4% per 4
o
C (1.8
o
F) from 40
o
C to 55
o
C (104
o
F to 131
o
F)
Output Current (Amps)
Continuous RMS
Continuous 0-Peak
Peak 0-Peak
3
4.2
12.7
6
8.5
25.5
12
17
42.5
24
34
67.9
Continuous Output Power
Input = 240 VAC,
KW
0.6 1.25 2.5 5
Input = 400 VAC,
KW
1 2 4.2 8.3
Input = 480 VAC,
KW
1.2 2.5 5 10
Peak Output Power
Input = 240 VAC,
KW
1.8 3.75 6.25 10
