8.1.6 Auxiliary Feedback Port
The 15-pin female Auxiliary Feedback connector (labeled “J8 AUX FEEDBACK” on
the front of the Drive) provides the interface between the S200-DLS Drive and a
feedback device.
• Pin descriptions are provided in Table 8-5
• Pin assignments are provided in Table 8-6
• The available Flying Lead cable is described in Table 8-7.
• Available Breakout Boxes and Cables are described in Table 8-8.
• Breakout Box dimensions are shown in Figure 8-3
• Breakout Board dimensions are shown in Table 8-4
Table 8-4: Digital Link Port “IN” to “OUT” Cables
Part Numbers:
.3 M (1.0 ft): M.1302.8285 .6 M (2.0 ft): M.1302.8286
1 M (3.3 ft): M.1302.8287 2 M (6.6 ft): M.1302.8288
3 M (9.8 ft): M.1302.8289 5 M (16.4 ft): M.1302.8300
10 M (32.8 ft): M.1302.8301 15 M (49.2 ft): M.1302.8302
30 M (98.4 ft): M.1302.8303
Cable type: CAT-5 (or better), 28 AWG, shielded, twisted pair, 8 conductor.
8-Pin RJ-45 Plug (to
Digital Link Port “OUT”,
face view)
8-Pin RJ-45 Plug (to Digital
Drive “IN”, face view)
Pin Signal Pin Signal Notes
1 Transmit Data + 1 Receive Data + Twisted
2 Transmit Data - 2 Receive Data - Pair
3 Receive Data + 3 Transmit Data + Twisted
6 Receive Data - 6 Transmit Data - Pair
4 None 4 None Twisted
5 None 5 None Pair
7 None 7 None Twisted
8 None 8 None Pair
Shell Drain Shell Drain
