7.4.2 Physical/Electrical Data for 460V Size 1 Smart Drives
Model
MMC-SD-1.3-460 (-D) MMC-SD-2.4-460 (-D)
Part Numbers
Analog
Digital, no BiSS
Digital, BiSS
M.1302.5093
M.1302.8133
M.3000.0464
M.1302.5094
M.1302.8134
M.3000.0465
Physical
Weight
10 lbs.
Electrical Specifications
AC Input Specifications
Wire Size
1mm
2
to 2.5mm
2
(16-12AWG)
Screw Torque Not specified
Input Configuration
Industrial system with direct low impedance earthed star
point (TN or TT mains). Do not use with IT mains or corner
grounded delta.
Inductance .4% (min) to 4% (max)
Nominal Input Power 1.94kVA 3.33kVA
Input Voltage 207-528 VAC (400 VAC nominal), 3 Phase
Input Frequency 47-63Hz
Nominal Input 2.44A RMS 4.18A RMS
NOTE: Nominal Input Current is specified for nominal input voltage of 460 VAC.
Maximum Inrush 4.56A RMS 7.81A RMS
Power Loss 34W 60W
AC Output Specifications
Continuous Output
Current RMS (0-
Peak)
2.1A (3.0A) 3.9A (5.5A)
Continuous Output Power
Input = 230 VAC .65kW 1.2kW
Input = 460 VAC 1.3kW 2.4kW
Peak Output Current
(0-Peak)
6.0A 11.0A
Output Frequency 0-450Hz
