7.4.3 Physical/Electrical Data for 460V Size 2 Smart Drives
Model
MMC-SD-4.0-460
(-D)
MMC-SD-6.0-460
(-D)
MMC-SD-8.0-460
(-D)
Part Numbers
Analog
Digital, no BiSS
Digital, BiSS
M.1302.5095
M.1302.8135
M.3000.0466
M.1302.5096
M.1302.8136
M.3000.0467
M.1302.5097
M.1302.8137
M.3000.0468
Physical
Weight
16 lbs.
Electrical Specifications
AC Input Specifications
Wire Size
1mm
2
to 2.5mm
2
(16-12AWG)
Screw Torque 0.6 Nm
Input Configuration
Industrial system with direct low impedance earthed star point (TN or TT
mains). Do not use with IT mains or corner grounded delta.
Inductance .4% (min) to 4% (max)
Nominal Input
Power
5.6kVA 8.6kVA 11.8kVA
Input Voltage 207-528 VAC (400 VAC nominal), 3 Phase
Input Frequency 47-63Hz
Nominal Input
Current
7A RMS 10.8A RMS 14.8A RMS
NOTE: Nominal Input Current is specified for nominal input voltage of 460 VAC. Approximate
Current for input voltages between 400 and 480 VAC = (listed current) x input voltage/460
Maximum Inrush
Current
13.2A RMS 20.2A RMS 27.7A RMS
Power Loss 102W 150W 204W
