Kollmorgen MMC Smart Drive

196 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 460V 3-PHASE MMC SMART DRIVE
AC Output Specifications
Continuous Output
Current RMS (0-
Peak)
6.4A (9.0A) 9.6A (13.5A) 12.7A (18.0A)
Continuous Output Power
Input = 230 VAC 2.0kW 3.0kW 4.0kW
Input = 460 VAC 4.0kW 6.0kW 8.0kW
Peak Output Current
(0-peak)
18.0A 27.0A 36.0A
Output Frequency 0Hz to 450Hz
Internal Holding Brake Driver
Maximum Current 0.5A
DC Input Power Specifications (24VDC)
Input Voltage Range 24VDC +15% -10%
Typical Input
Current
1050mA
Typical Input
Wattage
25W
Inrush Current 4A for 10ms
Energy Absorbtion Specifications
DC Bus
Capacitance
(Internal)
470μF 705μF
Shunt Switch
Threshold
780VDC
Joules available for energy absorption
230V motor w/230V
line input
13 joules 19 joules
460V motor w/230V
line input
188 joules 177 joules
460V motor w/460V
line input
44 joules 66 joules
