MMC Smart Drive Hardware Manual - 460V 3-PHASE MMC SMART DRIVE
AC Output Specifications
Continuous Output
Current RMS (0-
Peak)
19.5A
(27.5A)
25.8A
(36.5A)
38.9A
(55.0A)
(49.0A (69.3A)
Continuous Output Power
Input = 230 VAC 6.0kW 8.0kW 12.0kW 15.0kW
Input = 460 VAC 12.0kW 16.0kW 24.0kW 30.0kW
Peak Output Current
(0-peak)
55.0A 73.0A 110.0A 110.0A
Output Frequency 0Hz to 450Hz
Internal Holding Brake Driver
Maximum Current 0.5A 1.0A
DC Input Power Specifications (24VDC)
Input Voltage Range 24VDC +15% -10%
Typical Input Current 1750mA
Typical Input
Wattage
42W
Inrush Current 4A for 10ms
Energy Absorbtion Specifications
DC Bus Capacitance
(Internal)
820μF 1230μF 1640μF 2000μF
Shunt Switch
Threshold
780VDC
Joules available for energy absorption
230V motor w/
230V line input
22 joules 33 joules 45 joules 553 joules
460V motor w/
230V line input
206 joules 309 joules 412 joules 502 joules
460V motor w/
460V line input
76 joules 114 joules 152 joules 185 joules
