Kollmorgen MMC Smart Drive

Kollmorgen - December 2011 155
MMC Smart Drive Hardware Manual - 460V 3 PHASE MMC SMART DRIVE NEXTGEN
Figure 6-5: BR+ and BR- Wiring Examples
NOTE
Use of a diode (as shown) or an external RC type snubber is highly recom-
mended for use with inductive loads, especially DC inductive loads.
BR+
BR-
Using External Power Source
Brake
1N4004
Drive
+24VDC
Control
Brake
+24V COM
