Kollmorgen MMC Smart Drive

242 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - MOTOR CABLES & CONNECTORS
Table 9-5: LSM/MSM Motor Power Connector Flying Lead Cables
Connector Pinout
Wire
Color
Wire
Number
Signal
Type
Size 1 Power
Connector
Size 1.5.1
Power
Connector
Size 1.5.2
Power
Connector
Black (1) 1U2 Out 1 U
Black (2) 1V2 Out 3 V
Black (3) 1W2 Out 4 W
Green/
Yellow
PE Ground 2
Black (5) Brake+ Out A +
Black (6) Brake- Out B -
B
A
C
D
3
1
4
+
V
U
1
2
W
