MMC Smart Drive Hardware Manual - MOTOR CABLES & CONNECTORS
8AWG
Size 1.5.2 in
Table 9-5 on
page 242
1 M (3.3 ft) M.1302.1146
3 M (9.8 ft) M.1302.1147
6 M (19.7 ft) M.1302.1148
9 M (29.5 ft) M.1302.1149
15 M (49.2 ft) M.1302.1150
6AWG Consult Factory
1 M (3.3 ft) M.3000.tbd
3 M (9.8 ft) M.3000.tbd
6 M (19.7 ft) M.3000.tbd
9 M (29.5 ft) M.3000.tbd
15 M (49.2 ft) M.3000.tbd
4AWG Consult Factory
1 M (3.3 ft) M.3000.tbd
3 M (9.8 ft) M.3000.tbd
6 M (19.7 ft) M.3000.tbd
9 M (29.5 ft) M.3000.tbd
15 M (49.2 ft) M.3000.tbd
2AWG Consult Factory
1 M (3.3 ft) M.3000.tbd
3 M (9.8 ft) M.3000.tbd
6 M (19.7 ft) M.3000.tbd
9 M (29.5 ft) M.3000.tbd
15 M (49.2 ft) M.3000.tbd
