234 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - S200-DLS DRIVE
Drive I/O Port DC Outputs
Configuration
•4 optically isolated 24V DC outputs
•Active high
•Current sourcing only (current into load)
•Short circuit and overload protected
Maximum current 50mA per output
Voltage range 24VDC +15%-10%
Time delay on for resis-
tive loads
50 µsec. max
Time delay off for resis-
tive loads
50 µsec. max
Leakage current in off
state
0.5 mA max
Digital Link In/Out Ports
“In” port
Sends and receives high speed data to and from connect-
ed MMC-SD’s “Out” port.
“Out” port
Sends and receives high speed data to and from connect-
ed MMC-SD’s “In” port.
Cable Type
Shielded, Straight Pinned, CAT5 or better (CAT5e, CAT6,
etc.)
Maximum Cable
Length
30 m (98.4 ft)
Conformity
CE Marked
Note: Only units Rev 1
or higher are CE
Marked.
Conforms to Low Voltage Directive 73/23/EEC (amended
by 93/68/EEC) and EMC Directive 89/336/EEC (amended
by 92/31/EEC and 93/68/EEC).
Conformance is in accordance with the following stan-
dards:
EN 50178 and EN61800-3
UL and C/UL Recog-
nized
E233454
RoHs The S200-DLS Drives are not RoHs compliant
