MMC Smart Drive Hardware Manual - 460V 3 PHASE MMC SMART DRIVE NEXTGEN
Table 6-25: External Regen Resistors
For Drive Shunt Resistor Module
Part
Number
MMC-SDN-1.8-
460-D
MMC-SDN-3.6-
460-D
MMC-SDN-7.2-
460-D
33Ω, 100W Cont. Power, 160W Peak Power BAFP-100-33
33Ω, 200W Cont. Power, 320W Peak Power BAFP-200-33
33Ω, 250W Cont. Power, 400W Peak Power BAR-250-33
33Ω, 500W Cont. Power, 800W Peak Power BAR-500-33
33Ω, 1.5kW Cont. Power, 2.4kW Peak Power BAR-1500-33
33Ω, 3kW Cont. Power, 4.8kW Peak Power BAR-3000-33
MMC-SDN-14.4-
460-D
23Ω, 600W Cont. Power, 960W Peak Power BAR-600-23
23Ω, 1kW Cont. Power, 1.6kW Peak Power BAR-1000-23
23Ω, 2kW Cont. Power, 3.2W Peak Power BAS-2000-23
23Ω, 3kW Cont. Power, 4.8kW Peak Power BAS-3000-23
23Ω, 4kW Cont. Power, 6.3kW Peak Power BAS-4000-23
