MMC Smart Drive Hardware Manual - 460V 3 PHASE MMC SMART DRIVE NEXTGEN
Conformity
CE Marked (pending).
Conforms to Low Voltage Directive 73/23/EEC (amended
by 93/68/EEC) and EMC Directive 89/336/EEC (amended
by 92/31/EEC and 93/68/EEC).
Conformance is in accordance with the following stan-
dards:
EN 50178 and EN61800-3
UL and C/UL Listed (pending) E233454
DC Input Power Specifications (24VDC)
Input Voltage Range 24 VDC +/-10%
Typical Input Current (does not
include Brake Output current)
1A (3A, 6A, and 12A Drives), 2A (24A Drive)
Typical Input Wattage 15.6 W
Inrush Current Not Specified
F1 and F2 Feedback Inputs
Input receiver type Maxim 3098 A quad B differential RS422 receiver
Encoder signals Differential quadrature
Input threshold ±200 mV
Input termination 150Ω, provided internally
Maximum input voltage 5V peak to peak differential -10 to +13.2V common mode
Maximum input signal frequency 720 K Hz (2.88 M feedback counts per second)
+5V regulated output F1 = 350ma, F2 = 200ma
General Purpose Inputs
Configuration
•6 optically isolated 24V DC Inputs
•Sink or Source in group of 6
•2 optically isolated 24V DC Fast Inputs
•Sink or Source in group of 2
Guaranteed On 15 VDC
Guaranteed Off 5 VDC
Time delay on 1 ms max. (3us for Fast Inputs)
Time delay off 1 ms max (50us for Fast Inputs)
Input voltage Nominal 24 VDC, maximum 30 VDC
