Kollmorgen MMC Smart Drive

178 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 460V 3-PHASE MMC SMART DRIVE
Figure 7-5: Connectors on the Size 3 460V Drive
Ba-
Ba+
1C1
1D1
PE
Line Power Connector
PE
1U2
1V2
1W2
Motor Power Connector
1U1
1V1
1W1
24V Power
Connector (J1)
+24V
+24V
Mains On
Shunt On
24V Com
24V Com
Pin
1
2
3
4
5
6
Motor Brake
Pin
1
2
3
4
5
6
Connector (X101)
+24VBRK
Brake+
24VCOM
N/C
N/C
Brake-
(Located under cover)
PE
PiCPro Port (P1)
Feedback
Connector (F1)
Drive I/O
Connector (IO)
Not Used
PiCPro Port (P1)
Feedback
Connector (F1)
Drive I/O
Connector (IO)
Feedback
Connector (F2)
*See Section 5.1
Node Address
Rotary Switches
Digital LInk
Connectors
Not Used
*See Section 5.1
Analog Interfaced
Digital Interfaced
(IN/OUT)
MMC-SD
MMC-SD
