MMC Smart Drive Hardware Manual - 460V 3-PHASE MMC SMART DRIVE
External Shunt
Maximum shunt
resistor current
67A (AC) 100A (AC) 100A (AC)
Minimum shunt
resistor
12Ω 8Ω 8W
Maximum shunt
resistor power at
minimum shunt
resistor
53kW 80 80kW
Fan (X36 Connector)
Input Voltage 230VAC (nominal), 207VAC to 253VAC, 50/60HZ
Input Current 1A Max
Power Loss 87W
