MMC Smart Drive Hardware Manual - DRIVE RESIDENT DIGITAL MMC CONTROL
Figure 12-7: Connecting Output Devices to the General I/O Port (C5)
To
Drive Resident Digital
GENERAL
CONNECTOR DC
OUTPUT PINS
DC Power Supply
+
_
SPG
Common
DCOUT5
LOAD
5
7
9
6
8
3
17
4
18
2
15
1
14
16
MMC Control
DCOUT1
DCOUT2
DCOUT3
DCOUT4
DCOUT6
DCOUT7
DCOUT8
24VDCIN
IO24C
