MMC Smart Drive Hardware Manual - 460V MMC SMART DRIVE DC BUS SHARING
Table A-2: Drive Bus Capacitance and energy Absorption Capability
Drive
a
MMC
Smart
Drive Bus
Capaci-
tance
(μFarad)
Energy
Absorption
at 230V Line
Input and
230V Motor
(Joules)
Energy
Absorption
at 230V Line
Input and
460V Motor
(Joules)
Energy
Absorption
at 460V Line
Input and
460V Motor
(Joules)
460V Size 1
MMC-SD-1.3-460 110 3 28 10
MMC-SD-2.4-460 240 7 60 22
460V Size 2
MMC-SD-4.0-460 470 13 118 44
MMC-SD-6.0-460 470 13 118 44
MMC-SD-8.0-460 705 19 177 66
460V Size 3
MMC-SD-12.0-
460
820 22 206 76
MMC-SD-16.0-
460
1230 33 309 114
MMC-SD-24.0-
460
1640 45 412 152
MMC-SD-30.0-
460
2000 55 502 185
460V Size 4
MMC-SD-42.0-
460
1880 50.4 472 173
MMC-SD-51.0-
460
2350 63.1 591 218
MMC-SD-65.0-
460
3055 82 768 284
230 V
b
MMC-SD-0.5-460 1410 38
MMC-SD-1.0-460 1880 51
MMC-SD-2.0-460 1880 51
a. add suffix (-D) for Digital Drive
b. add suffix (-D) for Digital Drives and (-DN) for Digital Narrow Drives
