MMC Smart Drive Hardware Manual - 460V MMC SMART DRIVE DC BUS SHARING
Table B-1: kW Ratings for Powered Drive
Drive Model
Bus power
available for
linking to other
drives
Continuous
Current
(Amps)
Peak
Current
(Amps)
MMC-SD-1.3-460 2.0kW 3 6
MMC-SD-2.4-460 2.0kW 5.5 11
MMC-SD-4.0-460 5.0kW 9 18
MMC-SD-6.0-460 5.0kW 13.5 27
MMC-SD-8.0-460 5.0kW 18 36
MMC-SD-12.0-460 10.0kW 27.5 55
MMC-SD-16.0-460 10.0kW 36.5 73
MMC-SD-24.0-460 10.0kW 55 110
MMC-SD-30.0-460 10.0kW 69.3 110
MMC-SD-42.0-460 36.0kW 93.3 147
MMC-SD-51.0-460 45.0kW 117.4 184
MMC-SD-65.0-460 58.0kW 152.7 209
