KSB PumpDrive 2 - Page 141

10 Parameter List PumpDrive 2
141 of
212
Parameter Description Help text Possible settings Unit Factory setting
3-1-5 Commissioning Wizard Starting the commissioning wizard Run
3-2 Motor
3-2-1 Nominal Motor Data
3-2-1-1 Nominal Motor Power Nominal power of motor as per name plate Minimum to maximum limit of value range
set
Dependent on the
unit set
Dependent on
size
3-2-1-2 Nominal Motor Voltage Nominal voltage of motor as per name
plate
Minimum to maximum limit of value range
set
V Motor-specific
3-2-1-3 Nominal Motor
Frequency
Nominal frequency of motor as per name
plate
Minimum to maximum limit of value range
set
Hz Motor-specific
3-2-1-4 Nominal Motor Current Nominal current of motor as per name plate Minimum to maximum limit of value range
set
A Dependent on
size
3-2-1-5 Nominal Motor Speed Nominal speed of motor as per name plate Minimum to maximum limit of value range
set
rpm Motor-specific
3-2-1-6 Nominal Cos Phi Value Cos phi of motor at nominal power 0,00 … 1,00 Motor-specific
3-2-2 Motor Speed Limitation
3-2-2-1 Minimum Motor Speed 3-11-1-1 … 3-2-2-2 rpm Motor-specific
3-2-2-2 Maximum Motor Speed 3-2-2-1 … 3-11-1-2 rpm Motor-specific
3-2-3 Thermal motor
protection
3-2-3-1 PTC Analysis Motor temperature monitoring ▪ OFF
▪ ON
Motor-specific
3-2-3-2 Thermal Motor
Protection Behaviour
Behaviour for detection of excessive motor
temperature
▪ Self-acknowledging
▪ Non-self-acknowledging
Non-self-
acknowledging
3-2-4 Motor Direction of
Rotation
Setting the direction of rotation of the
motor with respect to the motor shaft
▪ Clockwise
▪ Anti-clockwise
Clockwise
3-2-5 Motor Standstill Heater OFF
3-2-5-1 Motor Standstill Heater Heating the motor via the motor windings OFF
ON
3-2-5-2 Heating Current Heating current in % of nominal motor
current
0,00…50,00 % 20,0
3-3 Frequency inverter
3-3-1 Motor Control Method Selecting the control method ▪ Asynchronous Motor V/f Control
▪ Asynchronous Motor Vector Control
▪ SuPremE Vector Control
Motor-specific
