1-S13
MX5100, WSM
ENGINE
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-10, G-11.)
[TRACTOR BODY]
W1055580
Item N·m kgf·m lbf·ft
Start B terminal mounting nut 7.8 to 9.8 0.8 to 1.0 5.8 to 7.2
Steering wheel mounting nut 48.0 to 55.9 4.9 to 5.7 35.4 to 41.2
Power steering main delivery hose retaining nut 46.6 to 50.9 4.8 to 5.2 34.4 to 37.6
Power steering turning delivery hoses retaining nut 24.5 to 29.4 2.5 to 3.0 18.1 to 21.7
Engine and clutch housing mounting screw and nut
(M12, grade7)
77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Engine and clutch housing mounting stud bolt 39.2 to 49.0 4.0 to 5.0 28.9 to 36.2
Front axle frame mounting screw (M10) 60.8 to 70.5 6.2 to 7.2 44.9 to 52.1
Front axle frame mounting screw (M12) 102.9 to 117.6 10.5 to 12.5 76.0 to 86.8
Clutch pressure plate mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.3
