Kubota MX5100 - Check Points of Initial 50 Hours

G-19
MX5100, WSM
G GENERAL
[2] CHECK POINTS OF INITIAL 50 HOURS
Adjusting Clutch Pedal Free Play
1. Stop the engine and remove the key.
2. Slightly depress the clutch pedal and measure free travel at top
of pedal stroke.
3. If adjustment is needed, loosen the lock nut, remove the cotter
pin and adjust the rod length within acceptable
limits.
4. Retighten the lock nut and split the cotter pin.
W10743050
Changing Engine Oil
CAUTION
• Be sure to stop the engine before changing the oil.
• Allow engine to cool down sufficiently, oil can be hot and
can burn.
1. To drain the used oil, remove the both drain plugs (1) at the
bottom of the engine and drain the oil completely into the oil pan.
2. After draining reinstall the drain plug.
3. Fill with the new oil up to upper notch on the dipstick (2).
(See page G-8.)
W10145330
Brake pedal free play
Factory spec.
15 to 20 mm
(5/8 to 13/16 in.)
Keep the free travel in the
right and left brake pedals
equal.
Clutch pedal free play
20 to 30 mm
(13/16 to 1-3/16 in.) on
the pedal
(1) Clutch Rod
(2) Nut
(3) Cotter Pin
A : Free Travel.
Engine oil capacity (with filter)
8.0 L
8.5 U.S.qts
7.0 Imp.qts
(1) Oil Inlet
(2) Dipstick
(3) Drain Plug
(A) Oil level is acceptable within this
range.
